Ultra |
|
Models | | P5 DSP Ultra | DSP16 Ultra |
Components | DSP Chip | ADAU1463 x 3PCS | ADAU1463 x 3PCS |
DAC Chip | 2 x ESS9083Pro w/ 7 DAC Filter Settings | 2 x ESS9083Pro w/ 7 DAC Filter Settings |
ADC Chip | 2 x AK5558VN |
Opamp | Proprietary |
Capacitors | High Temperature for High Reliability to 105°C electrolytics and WIMA film Caps | High Temperature for High Reliability to 105°C electrolytics and WIMA film Caps |
Players | Music Formats | HiRes: DFF / DSF / DSD Up to 256 Hi Res Uncompressed: WAV / FLAC / APE / AIFF / AIF Compressed: MP3 / AAC / OGG / WMA | NA |
Music Inputs | USB Host x 3 1 x USB-DAC (to 192/32bit) Opt. and Coax (to 192/24bit BT 5.0 aptX HD/AAC/SBC | 1 x USB-DAC (to 192/32bit) Opt. and Coax (to 192/24bit) BT 5.0 aptX HD/AAC/SBC |
Control Inputs | BT Wireless Remote Wi-Fi Mobile App Wired IPS Panel Controller included | Standard Controller |
|
Processor Functions | PC Connection | USB B |
Processing Functions (See delay below) | Crossover Frequency: 20Hz ~ 20kHz @ 1dB steps, Master Gain: 0 ~ 60dB, Channel gains: -20dB ~ +5dB Polarity: Phase Reversal 0 or 180, EQ filters Q 0.5 ~ 15 @ 0.1 steps, Input Mixer, Three Linking Functions: Volume Linking- Absolute or Relative, EQ Linking - Relative or Absolute, Crossover Linking - With EQ link on, Freq Link button will link crossovers |
Delay | 0 ~ 20ms / 0.005ms Steps |
Output EQ | EQ bands: All Channels 31 @ ± 15dB in 0.1dB Steps, Filter Functions: Peak / High Shelf / Low Shelf / 1st order All Pass/ 2nd Order All Pass |
Crossover | Butterworth & Bessel: 6, 12, 18, 24, 30, 36, 42, 48dB / Linkwitz: 12, 24, 36dB |
XO Phase Rotation | Variable Phase shift at HP and LP filters from 0° ~ 359° |
Inputs | 16 x Hi / 2 x RCA/Opt./Coax/USB-DAC |
Input EQ | EQ bands: All Channels 5 bands @ ± 15dB in 0.1dB Steps Filter Functions: Peak / High Shelf / Low Shelf / 1st order All Pass/ 2nd Order All Pass Input Delay: 0 ~ 10ms in 0.02 Steps |
General / Amplifier | Frequency Resp: | 10Hz ~ 80kHz |
Operating Voltage | 11v-16v |
Input Sens (V) RCA | | |
Input Sens (V) Hi | |
RCA Out Voltage | 16 x 6V |
RCA Out Specs | THD+Noise 0.00018 S/N >125 |
Amp Outputs | THD+Noise <0.03 S/N >100dB | NA |
Dimensions (mm) | 303 x 231 x 50 | 304 x 231 x 50 |
|
Start-Stop ready | Yes |
EPS (Intelligent High-Level Input-Error Protection System) | Yes |
Finish | Balck Anodized Aluminum |
Auto Turn On via DC Offset or Signal Sensing | Yes |
Remote Turn on Output | Yes |
Clipping LED’s | No |
Built in Bluetooth | aptX HD |
Built In Wifi | Yes | |
THD+Noise RCA | 0.00018% |
S/N ratio RCA | >125dB |
THD+Noise Amplifier | NA |
S/N ratio Amplifier | NA |
Fuse Rating | 10A |
Input impedance: No Impedance adaptor needed | 6 Ohm High Level |
Controller | Wireless BT/Optional Wired IPS Display/ Mobile app | Standard Controller |
Input Mixer | Yes |
Presets | 8 |
Software Interface | PC 32bit W7 and up |
All Pass filters at input and output EQs | Both 1st Order and 2nd Order |
Navigation Mode w/ Input Priority | Yes |
Automatic Mode Switching Mixer | Yes |
Password Available | Yes |
Analog Noise Gate | Yes |
Variable Power Off Delay | Yes |
Seven DAC rolloff choices for ESS 9038 | Yes |
